- 6” PolyPlas™ woofer for big bass response
- JBL® HeatScape™ delivers great power handling
- Detailed high frequency sound reproduction
- Sit-anywhere EOS™ Waveguide sound
- Proprietary SSP™ reduces noise and signal lose
- Accurate frequency response
- Excellent audio output
- Magnetically shielded for video proximity
- Multiple placement options
ups.changezipcode ups.edit
Этот товар в данный момент недоступен.
- Распродано
Функции
6” PolyPlas™ woofer for big bass response
Stiffer cones deliver more uniform pistonic motion for deeper, tighter bass and improved midranges. PolyPlas™ gives maximum impact JBL® audio. You’ll experience serious, feel-it-in-your-bones bass and true sound that does justice to the artist’s original performance.
JBL® HeatScape™ delivers great power handling
The HeatScape™ motor structure envelops the voice coil with a large ceramic magnet and steel frame that protects the voice coil by dissipating heat. This increases power handling and gives you extremely low levels of harmonic distortion.
Detailed high frequency sound reproduction
A thin, but rigid, 1” pure titanium-laminate dome tweeter delivers accurate high frequency response, even when the volume is cranked up. A Mylar® dome makes way for open, smooth spacious sound, and a seamless transition between the middle and high frequencies.
Sit-anywhere EOS™ Waveguide sound
Elliptical Oblate Spheroidal TM (EOS) Waveguides, originally developed for JBL® Pro LSR studio monitors, disperse clean, high frequency sound more precisely across a wider listening area. There’s no “sweet spot.” Sit wherever you want.
Proprietary SSP™ reduces noise and signal lose
By taking the shortest possible route from the input terminals to the transducers – simplifying and shortening the path – this proprietary crossover design means you hear everything your TV and music source can dish out.
Accurate frequency response
From 55Hz to 40kHz, nothing is over- or underemphasized. You get a true, full sound range from deep bass tones to ultra-high frequencies.
Excellent audio output
With 75W of continuous power handling and 300W peak, the JBL® L810 has a robust, muscular delivery. It uses technology derived directly from JBL® Professional studio monitors and gives your home theater audio the unparalleled spaciousness and definition it demands.
Magnetically shielded for video proximity
Put the JBL® L820 anywhere that makes sense in your home theater set-up. It’s magnetically shielded for placement on the floor or wherever you want it, including right next to your TV or video display.
Multiple placement options
The JBL® L820 offers multiple mounting and placement options that allow it to fit almost anywhere, including bookshelves and walls. (Wall-mount hardware is included.)
Технические характеристики и скачанные файлы
Item#: L820-H
Общее
- Type
- Bookshelf Speakers
- Finish
- Black
- MSRP U.S.
- $749.95 per pair
Аудио
- Crossover Frequencies
- 600Hz, 3500Hz, 20kHz
- Maximum Recommended Amplifier Power
- 150W
- Nominal Impedance
- 8 ohms
- Sensitivity
- (2.83V@1m) 90dB
- Power Handling (Recommended)
- 75W
- Frequency Response
- 55Hz-40kHz
- Power Handling (Peak)
- 300W
Размеры
- Depth (in)
- 5
- Depth (mm)
- 127
- Height (in)
- 12-1/4
- Weight (lb)
- 19
- Weight (kg)
- 8.6
- Width (in)
- 15-1/2
- Width (mm)
- 391
- Height (mm)
- 311
Характеристики динамика
- Low-Frequency Transducer
- 6" PolyPlas Cone with Rubber Surround and Cast-Aluminum Chassis; HeatScape Motor Structure; Symmetrical Field Geometry (SFG); Oversized Kapton Voice Coil; Magnetic Shorting Ring
- Midrange Transducer
- 4"PolyPlas Cone with Rubber Surround and Cast-Aluminum Chassis; HeatScape Motor Structure
- Ultra High Frequency Transducer
- 19mm (3/4") Mylar Dome with Cast-Aluminum Chassis
- High-Frequncy Transducer
- 1" Pure-Titanium Dome with Cast Aluminum Chassis in JBL EOS Waveguide
- (1) Studio L820 4-Way, 6" High-Performance, Mirror-Image, Wall-Mount Satellite Speaker
- (1) Owner's Manual
